CTY Anti-Odor & Anti-Backflow Linear Floor Drain Product Introduction

The CTY anti-odor & anti-backflow linear floor drain features a bottom drainage structure with sloped drainage lines and a 10mm-wide skirt for enhanced waterproofing. Equipped with a patented water seal, it achieves a flow rate of 33L/min within a 43mm drainage space, offering exceptional odor and backflow prevention, resisting 1 atm backflow pressure. The removable water seal simplifies maintenance. Crafted from stainless steel 304, it offers multiple height, width, and length options to suit various needs. Choose from stainless steel, tile, or grille panels, paired with a vortex filter for efficient debris interception. Ideal for barrier-free shower rooms and more, with customization options available.

 Key Features

1. Linear Design, Minimalist Aesthetics

  - Sleek linear design seamlessly integrates with flooring, enhancing modern spaces.

2. Efficient Drainage & Odor Prevention

  - Patented water seal delivers 33L/min flow rate and resists 1 atm backflow pressure.

3. Enhanced Waterproofing

  - Sloped drainage lines and 10mm-wide skirt ensure robust waterproofing, preventing leaks.

4. Multiple Panel Options

  - Choose from stainless steel, tile, or grille panels to match various décor styles.

5. Easy Maintenance

  - Removable water seal simplifies cleaning and extends product life.

6. Efficient Filtration

  - Vortex filter effectively intercepts hair and debris, preventing clogs.

7. Durable Material

  - Stainless steel 304 resists corrosion and wear, ideal for humid environments.

8. Customizable Dimensions

  - Heights: 28mm/40mm; Widths: 55mm/70mm; Lengths: 300mm~2000mm (customizable).

Technical Specifications

- Height: 28mm / 40mm

- Width: 55mm / 70mm

- Length: 300mm~2000mm (customizable)

- Flow Rate: 33L/min

- Pressure Resistance: 1 atm (≈10m water column)

- Material: Stainless Steel 304

- Panel Options: Stainless Steel/Tile/Grille

- Filter Type: Vortex Filter

 Applications

- Barrier-free shower rooms

- Residential bathrooms, hotel restrooms

- Commercial drainage systems

 Customization Options

Tailor-made solutions for size, panel material (stainless steel/tile/grille), and logo engraving.

 Choose CTY for Worry-Free Drainage

The CTY anti-odor & anti-backflow linear floor drain redefines drainage standards with its linear aesthetics, efficient performance, and durable construction, ensuring cleanliness and beauty for your space.
